1. This infrared carbon fiber electric heater is available in stock and will be shipped on the same day of order payment!
2. The rated working voltage of the heating tube is 220V, which means that one end is connected to the live wire and the other end is connected to the neutral wire
3. If you need to connect 380V, you can use 2 tubes in series or 3 tubes in a star connection
4. The lampshade is made of aluminum magnesium alloy with a thickness of 1.28mm, and both ends are fixed with stainless steel brackets
Specification, model, rated power, external dimensions [length * width * height], fixed hole center distance/aperture, matching lamp tube length
Single tube 215mm/400W 400W 255 * 127 * 50mm 235 * 83mm, diameter 4mm 180mm
Double tube 215mm/800W 800W 255 * 127 * 50mm 235 * 83mm, φ 4mm 180mm
Single tube 235mm/400W 400W 275 * 127 * 50mm 255 * 83mm, diameter 4mm 200mm
Double tube 235mm/800W 800W 275 * 127 * 50mm 255 * 83mm, diameter 4mm 200mm
Single tube 285mm/500W 500W 325 * 127 * 50mm 305 * 83mm, diameter 4mm 250mm
Double tube 285mm/1000W 1000W 325 * 127 * 50mm 305 * 83mm, diameter 4mm 250mm
Single tube 335mm/600W 600W 375 * 127 * 50mm 355 * 83mm, diameter 4mm 300mm
Double tube 335mm/1200W 1200W 375 * 127 * 50mm 355 * 83mm, diameter 4mm 300mm
Single tube 385mm/600W 600W 425 * 127 * 50mm 405 * 83mm, diameter 4mm 350mm
Double tube 385mm/1200W 1200W 425 * 127 * 50mm 405 * 83mm, φ 4mm 350mm
Single tube 415mm/800W 800W 455 * 127 * 50mm 435 * 83mm, diameter 4mm 380mm
Double tube 415mm/1600W 1600W 455 * 127 * 50mm 435 * 83mm, diameter 4mm 380mm
Single tube 455mm/700W 700W 495 * 127 * 50mm 475 * 83mm, diameter 4mm 420mm
Double tube 455mm/1400W 1400W 495 * 127 * 50mm 475 * 83mm, diameter 4mm 420mm
Single tube 485mm/700W 700W 525 * 127 * 50mm 505 * 83mm, diameter 4mm 450mm
Double tube 485mm/1400W 1400W 525 * 127 * 50mm 505 * 83mm, diameter 4mm 450mm
Single tube 500mm/1000W 1000W 540 * 127 * 50mm 520 * 83mm, diameter 4mm 465mm
Double tube 500mm/2000W 2000W 540 * 127 * 50mm 520 * 83mm, diameter 4mm 465mm
Single tube 535mm/800W 800W 575 * 127 * 50mm 555 * 83mm, diameter 4mm 500mm
Double tube 535mm/1600W 1600W 575 * 127 * 50mm 555 * 83mm, diameter 4mm 500mm
Single tube 575mm/800W 800W 615 * 127 * 50mm 595 * 83mm, diameter 4mm 540mm
Double tube 575mm/1600W 1600W 615 * 127 * 50mm 595 * 83mm, diameter 4mm 540mm
Single tube 600mm/1000W 1000W 640 * 127 * 50mm 620 * 83mm, φ 4mm 565mm
Double tube 600mm/2000W 2000W 640 * 127 * 50mm 620 * 83mm, φ 4mm 565mm
Single tube 800mm/1200W 1200W 840 * 127 * 50mm 820 * 83mm, diameter 4mm 730mm
Double tube 800mm/2400W 2400W 840 * 127 * 50mm 820 * 83mm, diameter 4mm 730mm
Single tube 1000mm/1500W 1500W 1040 * 127 * 50mm 1020 * 83mm, φ 4mm 930mm
Double tube 1000mm/3000W 3000W 1040 * 127 * 50mm 1020 * 83mm, φ 4mm 930mm
